Specification of Iron Elbow SNI 20 x 20 x 3 mm - 6 M
Iron is an iron-shaped elbow elbow or an angle of 90 degrees. In general, angle iron used to make the metal shelving, water tower, construction of stairs, and other iron construction.
Angle iron / Equal Angle Bar
began uk. 30 X 30-200 X 200
Specifications: SNI 07.2054 1990 (Equivalent to JIS G 3101 and 3192
SIZE WEIGHT NOTE
A A S
20 x 20 x 3 mm - 6 M 5, 31 Kg
25 x 25 x 3 mm - 6 M 6, 72 Kg
30 x 30 x 3 mm - 6 M 8, 16 Kg
40 x 40 x 3 mm - 6 M 11 Kg
40 x 40 x 4 mm - 6 M 14, 5 Kg
40 x 40 x 5 mm - 6 M 18 Kg
45 x 45 x 4 mm - 6 M 16 44 Kg
45 x 45 x 5 mm - 6 M 20, 5 Kg
50 x 50 x 4 mm - 6 M 18 4 Kg
50 x 50 x 5 mm - 6 M 22 68 Kg
50 x 50 x 6 mm - 6 M 27 58 Kg
60 x 60 x 5 mm - 6 M 27 42 Kg
60 x 60 x 6 mm - 6 M 32, 52 Kg
65 x 65 x 6 mm - 6 M 35, 46 Kg
70 x 70 x 6 mm - 6 M 38, 28 Kg
70 x 70 x 7 mm - 6 M 44, 28 Kg
75 x 75 x 6 mm - 6 M 41, 22 Kg
75 x 75 x 7 mm - 6 M 47, 64 Kg
75 x 75 x 8 mm - 6 M 54, 18 Kg
75 x 75 x 9 mm - 6 M 60 Kg
80 x 80 x 6 mm - 6 M 43, 02 Kg
80 x 80 x 8 mm - 6 M 57, 96 Kg
90 x 90 x 8 mm - 6 M 65, 4 Kg
90 x 90 x 9 mm - 6 M 73, 2 Kg
90 x 90 x 10 mm - 6 M 79, 8 Kg
100 x 100 x 8 mm - 6 M 73, 2 Kg
100 x 100 x 10 mm - 6 M 90, 6 Kg
100 x 100 x 11 mm - 6 M 119, 4 Kg
120 x 120 x 12 mm - 6 M 130 Kg
125 x 125 x 12 mm - 6 M 140 Kg
130 x 130 x 9 mm - 6 M 129 Kg
130 x 130 x 12 mm - 6 M 140 Kg
150 x 150 x 12 mm - 6 M 164 Kg
150 x 150 x 15 mm - 6 M 202 Kg
200 x 200 x 15 mm - 6 M 272 Kg
200 x 200 x 16 mm - 6 M 301 Kg
200 x 200 x 20 mm - 6 M 358 Kg
200 x 200 x 25 mm - 6 M 442 Kg
250 x 250 x 25 mm - 6 M 562 Kg
CALCULATION WEIGHT / Calculation METHOD:
Width x Thickness x 6 x 0, 01 512 = weight (kg) / WEIGHT (Kg)
